SEN EDS provides advanced EMTP-based Insulation Coordination and Power System Transient Analysis services throughout Chennai. Using EMTP® software, we simulate complex electrical phenomena to optimize protection, improve system reliability, and ensure safe, standards-compliant operation across substations, wind farms, and industrial installations up to 400kV.

Our Core EMTP Analysis Services:

Insulation Coordination Studies – Ensure proper insulation levels and arrester placement for overvoltage protection.
Lightning Overvoltage Study – Analyze lightning strikes and resonance on overhead lines.
Switching Overvoltage Study – Evaluate TRVs and switching-related transients.
Transient Recovery Voltage (TRV) Analysis – Assess breaker performance during post-fault voltage oscillations.
Very Fast Transient Overvoltages (VFTO) – Identify and mitigate fast-front transients in GIS systems.
Harmonic Analysis – Detect and control harmonic distortions in power networks.
Sub-Synchronous Control Interaction (SSCI) – Study turbine-network dynamics in series-compensated wind systems.
Transient Stability Studies – Evaluate rotor angle stability during grid disturbances.
Low Voltage Ride Through (LVRT) – Ensure grid compliance and generator performance during faults.

Why Choose SEN EDS

Specialized in EMTP® Simulations – Proven accuracy in transient and overvoltage studies.
Customized Engineering Reports – Project-specific, regulatory-compliant documentation.
Comprehensive System Understanding – Across transmission, distribution, and renewable networks.
ISO 9001:2015 Certified – Assured quality and process reliability.
Experience with 400kV Systems – Expertise in AIS, GIS, and hybrid substations.
End-to-End Consulting – From field study to implementation support.

SEN Electrical Design Systems

4.1

Based on 21 reviews

review us on

Neduncheziyan G

02:11 28 Apr 23

Nice place to learn and work...

Janakiraman L

06:55 08 May 19

Experience stuff. Gain more knowledge about Electrical Detailed Design. And also ETAP training very well.

Vinoth Kumar Pankaj

05:00 08 May 19

Professional and experienced faculty. Explaining the concepts in a very easy and understandable way.

Balakrishnan Krishnan

19:41 17 Mar 17

Awesome training Place for Electrical Design EngineeringExcellent Faculty.

“SEN EDS helped us resolve insulation failures through precise EMTP coordination studies.”

Ravi K

“Their lightning overvoltage analysis identified key surge issues we weren’t aware of.”

Ananya S

“Switching transient study by SEN EDS reduced our transformer stress significantly.”

Vikas M

“TRV and VFTO reports were detailed and critical in optimizing our 220kV GIS system.”

Preeti R

“Reliable and technically competent—our harmonic issues were solved in one cycle.”

Amit J

“SEN EDS handled our SSCI risks in a wind project with precision. Excellent support!”

Priya N

Strengthen Your Grid with SEN EDS

Get high-accuracy EMTP simulations and insulation coordination studies that protect and optimize your electrical infrastructure. Contact SEN EDS for Insulation Coordination Services in Chennai.

SEN EDS offers Engineering Consultancy, Detailed Engineering Services and Power System Engineering Services (ETAP & DIgSILENT & PSCAD) for Switchyard up to 400kV Substation, Port, Industrial Project (Oil and Gas Plant, Steel Plant, Thermal Power Plant, Cement Plant, Water Treatment Plant), Grid Impact Study and Grid Code Compliance (UK, Oman, KSA, UAE, etc.), Airport Project, Specializing in Renewable Energy (Solar and Wind with BESS Plant)
